Allround 3 high stool with foot ring, Duotec fabric black, seat 560-830 mm, blue colour ring - Bimos 9461-6801-3277
The Allround 3 stool lifts the seat to bench height, the gas spring with ring release covers 560 to 830 mm and the foot ring takes the weight off the legs. The 60 mm comfort cushion is covered in black Duotec fabric, a breathable cover for long stretches at one station. Glides give a firm stand and the blue colour ring assigns the stool to its workplace.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
When someone stays at one station for longer stretches, the cover decides the climate at the seat. The Allround 3 stool pairs a 60 mm comfort cushion with black Duotec fabric and covers a seat height of 560 to 830 mm. The standard foot ring supports the legs in the upper part of the range, and glides hold the stool in place as the user sits down.
At a glance
- Seat height 560 to 830 mm, that is 270 mm of travel via a gas spring with ring release, operated while seated and without tools.
- Glides instead of castors, the stool keeps its position while climbing on and sitting down.
- Foot ring as standard, it takes the weight of the legs in the upper half of the adjustment range.
- Comfort cushion 60 mm thick, covered in black Duotec upholstery fabric.
- Footprint of only 54 cm diameter, which keeps circulation space between workstations clear.
- Colour ring in blue, so stools can be assigned to workstations, areas or shifts.
Applications
The stool 3 is intended for high work surfaces, that is benches, inspection and measuring stations, laboratory runs, counters and machine setup positions. The foot ring makes the upper seat height usable over longer periods as well.
ESD note
This version is not conductive, the property table lists ESD-safe as no. For workstations inside an EPA to DIN EN 61340-5-1, choose the dissipative E version of the stool system, in which cover, base and floor contact are matched to one another.
Technical data
| Manufacturer | Bimos |
|---|---|
| Manufacturer part number | 9461-6801-3277 |
| Model range | Allround stool 3 |
| Chair version | glides |
| Seat height adjustment | 560 to 830 mm |
| Adjustment travel | 270 mm |
| Height adjustment control | gas spring with ring release |
| Upholstery material | Duotec fabric |
| Upholstery thickness | 60 mm |
| Upholstery colour | black |
| Colour ring finish | blue |
| Colour | black |
| Base colour | black |
| Five-star base | yes |
| Footprint diameter | 540 mm |
| Foot ring | yes |
| ESD-safe | no |
| Battery included | no |
| Sales unit | 1 piece |
| Content unit | 1 piece |
| Weight | 0.1 kg |
| Manufacturer Nr. | 9461-6801-3277 |
| GPSR manufacturer information | Bimos GmbH & Co. KG, Brühlstraße 21, DE-72469 Meßstetten-Tieringen, www.bimos.com |
| Condition of article | New |
| Article authenticity | Original product |
| ESD version | TEC |
| Upholstery | Fabric |
| Base type | Glides |
| Seat height min (mm) | 560 |
| Seat height max (mm) | 830 |
| Backrest | none |
| Seat shape | Round seat |
| Series | Allround |
Scope of delivery
Supplied as a single item, sales unit 1 piece. Manufacturer Bimos, part number 9461-6801-3277.
