ESD vacuum formed tray T2-64 for Euro 3/4, 16 long compartments 504 x 15 x 8 mm - Licefa 2426070

Long, thin parts such as pin header strips, wires or narrow profiles do not fit into standard compartments. The T2-64 uses the full length of a Euro 3 or Euro 4 container and provides 16 channels of 504 x 15 x 8 mm.

Benefits

• 16 long compartments 504 x 15 x 8 mm for parts just over 50 cm long
• Compartment width 15 mm keeps narrow parts parallel and separated
• Recessed handle for lifting out the tray
• External size 551 x 352 x 36 mm for Euro 3 and Euro 4
• Dissipative polystyrene with 10⁴ to 10¹¹ Ω for electrostatic sensitive devices in an EPA according to DIN EN 61340-5-1
• Made in Germany

Applications

• Storage of long pin headers, wires and profiles in electronics production
• Order picking of bar stock
• Laboratory and prototyping
• Transport between EPA workstations

Compatible with

• Licefa transport and storage containers Euro 3 and Euro 4 ESD (base 551 x 352 mm)
