ESD mobile cabinet Rollboy Double 340/40, 24 drawers 40 mm, with work mat - Licefa 8900032

Connectors, relays and through-hole parts need more height than a strip of SMD tape. The Rollboy Double 340/40 ESD offers 24 drawers with 40 mm inside height in two modular cabinets side by side, and moves the complete component stock of a workstation to wherever the job is.

Benefits

• 24 drawers, each 340 x 250 x 40 mm inside, in two modular cabinets made of black dissipative PS
• Surface resistance 10^4 to 10^11 Ohm for protecting electrostatic sensitive devices in the EPA to DIN EN 61340-5-1
• Work mat on top plus wrist strap and coiled ground cable: the trolley doubles as a small ESD work surface
• 24 identification labels 70 x 25 mm included, every drawer can be marked straight away
• Frame of aluminium profiles and white coated chipboard on 4 twin castors, delivered fully assembled
• Drawers accept the dissipative vacuum formed trays of the series, made in Germany

Applications

• Manual assembly and repair with through-hole parts
• Service benches with changing spare parts
• Moving components between EPA workstations

Compatible with

• Dissipative vacuum formed trays for AFS 340/40 ESD, 3 to 30 compartments, 31 mm compartment height
• Drawer AFS 340/40 ESD as replacement or addition
• Identification label 70 x 25 mm for AFS 340
• Wrist strap and coiled ground cable of the Rollboy ESD series
