Lid for ESD waste bin 60 l, conductive, black, 560 x 275 x 40 mm - Warmbier 5180.860.D

An open waste container in the EPA leaves dust and packaging residue exposed, while a lid made of ordinary plastic would itself be an insulating surface. This Warmbier lid is made of volume-conductive polypropylene and closes the 60-litre bin without bringing a chargeable surface to the workstation.

Benefits

• Permanent, carbon-loaded conductive polypropylene, the conductivity is in the material and not only on the surface.
• Typical point-to-point resistance Rp-p of 10⁴ to 10⁵ ohm.
• Designed for the 60-litre multi-use bin, dimensions 560 x 275 x 40 mm.
• Marked with the ESD and recycling symbols, so the lid is recognisable as ESD equipment in the protected area.

Technical data

Applications

For covering the 60-litre square ESD waste bin at assembly stations, in testing and in electronics production areas.

Standards

According to the manufacturer, complies with IEC 61340-5-1.
