Ball Stage 450 VA for Stereo Microscopes, Tilt and Rotate the Object Freely - 4H Jena OI 203.11.001
Ball stage for microscope inspection on which the test object can be tilted and rotated freely. Solder joints and edges become visible from different angles without re-clamping the part.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Side solder menisci, pins under components or housing edges cannot be judged from above alone. The 4H Jena ball stage 450 VA carries the object on a ball-mounted plate. One movement of the hand tilts or rotates it under the microscope.
Benefits
- Tilt and rotate the object without re-clamping.
- Inspection from several angles in one pass.
- Complements stand and stereo microscope at the inspection station.
Applications
Inspection of solder joints and assemblies, incoming goods inspection, quality assurance in electronics and precision engineering.
Technical data
| Order number | OI 203.11.001 |
|---|---|
| Manufacturer | 4H Jena |
| Product type | ball stage |
| Sales unit | 1 piece |
| Weight | 12 kg |
| Manufacturer Nr. | OI 203.11.001 |
| HS-Code | 90119000 |
| GPSR manufacturer information | -4H- JENA engineering GmbH, Mühlenstraße 126, DE-07745 Jena, www.4h-jena.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
