ESD side cutting pliers 102 mm with 29 degree head for wire up to 0.6 mm - Weller GA54JVN

Cutting above a board with a straight head easily tips the tool against neighbouring parts. The Xcelite GA54JVN angles the edge by 29 degrees and cuts soft copper wire up to 22 AWG, equal to 0.6 mm, flush.

Benefits in use

• Head angled by 29 degrees, the edge works directly above the board plane.
• Flush cut on soft copper wire up to 22 AWG, equal to 0.6 mm.
• Cutting length 11.1 mm at a head length of 11.1 mm for short, controlled cuts.
• Head width 11.1 mm and head thickness 7.1 mm for access between closely spaced parts.
• Compact overall length of 101.6 mm, declared ESD safe by the manufacturer.

Technical data

Applications

Shortening leads above the board, rework on populated assemblies, fine assembly work in electronics production.

ESD and compliance

The manufacturer declares the tool as ESD safe, so it belongs at workstations that handle static sensitive devices. The manufacturer is WELLER Tools GmbH in Besigheim, Germany.
