162 iS PH/S VDE insulated screwdriver for PlusMinus screws (Phillips/slotted), reduced blade, # 1 x 80 mm - Wera 05006455001

PlusMinus screws on terminal blocks, fuse boxes, switches and relays are often recessed deep in the housing. The 162 iS PH/S combines the Phillips/slotted profile in size # 1 with a reduced blade diameter, so the 80 mm blade reaches recessed screws on systems up to 1,000 V.

Benefits

• Reduced blade diameter with integrated insulation for low-lying screw and spring elements.
• Phillips/slotted combination profile for PlusMinus screws.
• Insulated blade for secure work at 1,000 V.
• Kraftform Plus handle: hard zones for high working speed, soft zones for high torque transfer.
• Handle markings simplify finding and sorting, hexagonal anti-roll feature stops rolling away.

Applications

Electrical installation and control cabinet building, especially terminal blocks, fuse boxes, switches and relays with deeply recessed PlusMinus screws.

Standards and safety

Individually tested at 10,000 V in accordance with IEC 60900 for safe work up to 1,000 V. Impact strength tested at -40 °C.
