781 A/B VDE connector insulated, 1/4" square socket to 3/8" external square, 56 mm - Wera 05024690001

Name: 781 A/B VDE connector insulated, 1/4" square socket to 3/8" external square, 56 mm - Wera 05024690001
Brand: Wera
SKU: WR-05024690001
Price: 14.36 EUR
Availability: InStock

Wera ✓ Original product Brand new Made in Czechia

Insulated Zyklop VDE connector from 1/4" square socket to 3/8" external square, 56 mm long. Individually tested as per IEC 60900 at 10,000 V for safe working up to 1,000 V. The yellow insulation core shows damage to the red outer layer at once.

Net

€14.36

excl. VAT

Item WR-05024690001

Manufacturer no. 05024690001

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The 781 A/B VDE connector adapts a 1/4" ratchet or tool to 3/8" sockets for live working up to 1,000 V. Every part is individually tested at 10,000 V in accordance with IEC 60900.

Benefits

Adapts from 1/4" square socket to 3/8" external square and extends the insulated Zyklop system.
Individual testing at 10,000 V as per IEC 60900 for safe working up to 1,000 V.
2-component insulation: the yellow insulation core becomes visible as soon as the red outer layer is damaged.
Plastic coating protects surfaces from damage.

Applications

Electrical installation, switchgear and distribution board construction and service on live systems up to 1,000 V, whenever 3/8" sockets are to be driven with a 1/4" ratchet.

Standards and safety

Individually tested tool as per IEC 60900 at 10,000 V, approved for work up to 1,000 V.

Technical data

Input (tool side)	1/4" square socket
Output	3/8" external square
Length	56 mm (2 25/32")
Dimensions	56 x 18 x 18 mm
Weight	40 g
Insulation	VDE, 2-component, yellow core under red outer layer
Test voltage	10,000 V (individually tested)
Approved voltage	1,000 V
Manufacturer	Wera
Manufacturer Nr.	05024690001
EAN	4013288236524
HS-Code	82079030
GPSR manufacturer information	WERA Werkzeuge GmbH Korzerter Strasse 21-25 DE-42349 Wuppertal-Cronenberg www.wera.de
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Czechia
Height	18 mm
Width	18 mm
Norm	DIN EN IEC 60900
Overall length [mm]	56
