7770 open end insert 9x12 mm, 12 mm across flats - Wera 05078605001
Open end insert with 12 mm across flats for hexagon screw heads and nuts. Fits torque wrenches of the Click-Torque X series via its 9x12 mm square. Chrome-vanadium steel and pin lock for heavy loads and quick changes.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The 7770 open end insert turns a Click-Torque X torque wrench with 9x12 mm mounting into a tool for hexagon screw heads and nuts with 12 mm across flats. The pin lock holds the insert securely and allows a quick change to another size.
Benefits
- Exact fit: 9x12 mm square insert tool for torque wrenches of the Click-Torque X series
- Heavy-duty: chrome-vanadium steel for high loads
- Safe and quick: pin lock for safe working and rapid tool change
- Open jaw: 12 mm across flats for hexagon screw heads and nuts
Applications
Torque-controlled tightening of 12 mm hexagon screws and nuts with Click-Torque X torque wrenches, for example in assembly and maintenance.
Technical data
| Drive | Square 9x12 mm |
|---|---|
| Across flats | 12 mm |
| Test attachment dimension | 17.5 mm |
| Overall length | 41.3 mm |
| Head length | 24.7 mm |
| Width | 30.7 mm |
| Height | 7.2 mm |
| Material | Chrome-vanadium steel |
| Weight | 55 g |
| Manufacturer | Wera |
| Manufacturer Nr. | 5078605001 |
| EAN | 4013288196057 |
| HS-Code | 82079099 |
| GPSR manufacturer information | WERA Werkzeuge GmbH Korzerter Strasse 21-25 DE-42349 Wuppertal-Cronenberg www.wera.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Taiwan |
| Overall length [mm] | 41.3 |
