Festo ESS-30-EN (189342) Suction Cup

Name: Festo ESS-30-EN (189342) Suction Cup
Brand: Festo
SKU: FES-189342
Price: 1137 EUR
Availability: InStock

€1,137.00

Excl. 19% VAT , excl. Shipping Cost

Article

FES-189342

Manufacturer Nr.

ESS-30-EN

Suction Cup

The product may differ from the illustration

Frequently Bought Together

This Item: Festo ESS-30-EN (189342) Suction Cup
€1,137.00
Excl. 19% VAT , excl. Shipping Cost
Festo ESV-50-ES (191037) Vacuum Suction Cup
€1,454.00
Excl. 19% VAT , excl. Shipping Cost
Festo VASB-55-1/4-NBR (35414) Suction Cup
€2,407.00
Excl. 19% VAT , excl. Shipping Cost

Total price

Min. workpiece radius R [mm]	50
Nominal width [mm]	3,0
Suction diameter [mm]	30
Suction volumes [cm³]	2,120
Connection position	top
installation position	arbitrary
Allocate suction cup fixation	Size 4
Suction shape	Round, extra-deep
Operating pressure [bar]	0 to 0.95
Nominal operating pressure [bar]	-0,7
Operating medium	Atmospheric air based on ISO 8573-1:2010 [7:-:-]
Corrosion resistant class KBK	1 - low corrosion stress
Food compatibility	See expanded material information
ambient temperature [°C]	-10 to 70
Holding force for nominal operating pressure [N]	37,20
Shear force for nominal operating pressure [N]	24,5
Product weight [g]	9,2
Fastening type	Via vacuum connection
vacuum connection	M6
colour	black
Shore hardness	60 ± 5
Stud material	brass nickel-plated Zing and chrome plating
Material information	Copper and PTFE-free RoHs compliant
Suction cups material	NBR

More Information
Manufacturer Nr.	ESS-30-EN
Manufacturer	Festo
EAN	4052568042356
Weight	0.009900
HS-Code	84799070
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity	Original product
Condition of article	New
