The product may differ from the illustration
Festo vacuum component for safe gripping, holding and handling in automation.
Suction Cup ESS-50-EF - Festo 189353
FESTO
Original product
Net price (excl. VAT)
€53.62
Excl. 19% VAT ,
excl. Shipping Cost
Available
Fast shipping
Item
FES-189353
Manufacturer no.
ESS-50-EF
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.ESS-50-EF
EAN4052568078768
Customs tariff number84799070
ConditionNew
Article
FES-189353
Frequently Bought Together
-
This Item:
€53.62Excl. 19% VAT , excl. Shipping Cost
-
Suction Cup VAS-30-1/8-SI-B - Festo 1377752
€11.90Excl. 19% VAT , excl. Shipping Cost
-
Vacuum Suction Cup ESV-40-BS - Festo 191062
€13.12Excl. 19% VAT , excl. Shipping Cost
Total price
Festo vacuum component for safe gripping, holding and handling in automation. The key technical data of this genuine Festo article are listed below.
| Min. workpiece radius R [mm] | 100 |
| Nominal width [mm] | 3,0 |
| Suction diameter [mm] | 50 |
| Suction volumes [cm³] | 7,900 |
| Connection position | top |
| installation position | arbitrary |
| Allocate suction cup fixation | Size 4 |
| Suction shape | Round, extra-deep |
| Operating pressure [bar] | 0 to 0.95 |
| Nominal operating pressure [bar] | -0,7 |
| Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] |
| Corrosion resistant class KBK | 1 - low corrosion stress |
| Food compatibility | See expanded material information |
| ambient temperature [°C] | -10 to 200 |
| Holding force for nominal operating pressure [N] | 103,60 |
| Shear force for nominal operating pressure [N] | 60,0 |
| Product weight [g] | 23,4 |
| Fastening type | Via vacuum connection |
| vacuum connection | M6 |
| colour | <span class="farbe" style="background-color:#C6C6C6"></span> Grey |
| Shore hardness | 60 ± 5 |
| Stud material | brass nickel-plated<br>Alu wrought alloy nickel-plated<br>Zing and chrome plating |
| Material information | Copper and PTFE-free<br>RoHs compliant |
| Suction cups material | FPM |
| Manufacturer Nr. | ESS-50-EF |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568078768 |
| Weight | 0.023000 |
| HS-Code | 84799070 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Betriebsdruck max [bar] | 0.950000 |
