ESD bar type ionizer 780 mm, PNP - SMC IZS31-780P

The SMC IZS31-780P is an IZS31 series bar type ionizer with a 780 mm bar length. It neutralises electrostatic charges above workstations, conveyors and assembly lines, protecting sensitive electronic components against ESD damage.

Benefits

• Fast, even neutralisation across the full bar length
• Controlled ion balance with offset voltage within ±30 V
• PNP switching output for straightforward integration into machine control

Technical data

• Bar length: 780 mm
• Type: bar type ionizer (corona discharge)
• Output: PNP
• Applied high voltage: ±7000 V
• Offset voltage (ion balance): within ±30 V
• Supply voltage: 24 V DC ±10 %
• Ambient temperature: 0 to 50 °C
• Purge air: 0.05 to 0.1 MPa
• Electrode needles: tungsten

Applications

Electronics manufacturing, cleanrooms, assembly and test stations and handling lines where charges must be removed reliably.

Standards and compliance

Suitable for ESD control programmes to IEC 61340-5-1. CE marking, RoHS compliant.
