Suitable for stripping all common round and wet room cables from Ø 8.0 to 13.0 mm (e.g. NYM cable 3 x 1.5 mm² to 5 x 2.5 mm²). Also for use in junction or distribution boxes. Double-shell, hinged stripping tool. With opening spring and ratchet. Fastening clip for safe storage. Also with longitudinal cutter. Internal knife that can be pushed out. Stripping device for cross-sections 0.2 / 0.3 / 0.8 / 1.5 / 2.5 / 4 mm². with integrated cable guide for longitudinal cutting. Solid insulations (e.g. halogen-free) can be stripped more easily. - Stripping values square millimetres: 0.2 - 4mm² - Stripping values (diameter): Ø 8 - 13mm - Cable type: round cable, e. g.: 3 x 1.5 mm² to 5 x 2.5 mm² Round cable, e.g.: 3 x 1.5 mm² to 5 x 2.5 mm²
Suitable for stripping all common round and wet room cables from Ø 8.0 to 13.0 mm (e.g. NYM cable 3 x 1.5 mm² to 5 x 2.5 mm²)
Also for use in junction or distribution boxes
Double-shell, hinged stripping tool
With opening spring and ratchet
Fastening clip for safe storage
Product details
item number
WL46167
model
16 85 125 SB
manufacturer
KNIPEX
manufacturer item number
16 85 125 SB
dimensions (LxWxH)
181 mm x 86 mm x 36 mm
dimensions with packaging (LxWxH)
344 mm x 115 mm x 92 mm
Packaging volume
3.679 dm³
order unit
piece
type of packaging
blister packaging
RoHS conform
no
Stripping value of single wires
0.2 / 0.3 / 0.8 / 1.5 / 2.5 / 4 mm
cable type
Round cable, for example: 3 x 1.5 mm² up to 5 x 2.5 mm²
