Stereo microscope DZ.1600, binocular, EWF 10x/22 for laboratory, industry and education - Euromex DZ.1600
Stereo microscope DZ.1600, binocular, EWF 10x/22 DZ.1600 for laboratory, industry and education, Euromex. The modular DZ stereo microscope is built around a central 1:6.3 zoom unit and reaches total magnifications from 8x to 50x. The 1x plan apochromatic main objective offers 78 mm working distance; 0.5x (126 mm) and 2x (33 mm) are available as options. Ergonomic binocular head tilting 0-35°, dioptre adjustment of ± 5 on both eyepieces, interpupillary distance 55 - 75 mm, ports for one or two cameras. Stand with 100 mm stage plate, coaxial coarse and fine focus and 3 W LED incident and transmitted light, separately adjustable.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The modular DZ stereo microscope is built around a central 1:6.3 zoom unit and reaches total magnifications from 8x to 50x. The 1x plan apochromatic main objective offers 78 mm working distance; 0.5x (126 mm) and 2x (33 mm) are available as options. Ergonomic binocular head tilting 0-35°, dioptre adjustment of ± 5 on both eyepieces, interpupillary distance 55 - 75 mm, ports for one or two cameras. Stand with 100 mm stage plate, coaxial coarse and fine focus and 3 W LED incident and transmitted light, separately adjustable. Original accessories from Euromex are matched to the mechanics and optics of the corresponding microscope series. An existing workstation can thus be extended, or a wear part replaced, without exchanging the instrument. Before ordering, check the match by the manufacturer part number.
Benefits
- The modular DZ stereo microscope is built around a central 1:6.3 zoom unit and reaches total magnifications from 8x to 50x
- The 1x plan apochromatic main objective offers 78 mm working distance; 0.5x (126 mm) and 2x (33 mm) are available as options
- Ergonomic binocular head tilting 0-35°, dioptre adjustment of ± 5 on both eyepieces, interpupillary distance 55 - 75 mm, ports for one or two cameras
- Stand with 100 mm stage plate, coaxial coarse and fine focus and 3 W LED incident and transmitted light, separately adjustable
- Original part from Euromex
Applications
- Visual inspection and assembly in electronics production
- Laboratory and quality assurance
- Training and workshop
Technical data
| Brand | Euromex |
|---|---|
| Manufacturer part number | DZ.1600 |
| Product type | Stereo microscope DZ.1600, binocular, EWF 10x/22 |
| Suitable for | laboratory, industry and education |
| Eyepieces | EWF 10x/22 mm |
| Zoom | 1:6.3 |
| Total magnification | 8x - 50x |
| Working distance | 78 mm (1x main objective) |
| Illumination | LED incident and transmitted light, 3 W |
| Dimensions (L x W x H) | 440 x 390 x 680 mm |
| Colour | white |
| Weight | 12 kg |
| Manufacturer | Euromex |
| Manufacturer Nr. | DZ.1600 |
| HS-Code | 90111000 |
| GPSR manufacturer information | Euromex Microscopen bv Papenkamp 20 NL-6836 Bd Arnheim www.euromex.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | China |
