Pliers for electrical installation with 6 functions and opening spring, 200 mm, self-service blister - Knipex 13 92 200 SB

In electrical installation work, gripping, bending, stripping, crimping and cable cutting alternate minute by minute. The 13 92 200 SB pliers for electrical installation combine six of these steps in one 200 mm tool, so there is no need to keep reaching for the next pair of pliers.

Benefits

• Six functions in one tool, from gripping through bending and deburring to cable cutting, stripping and crimping.
• Smooth gripping surfaces at the tip hold single conductors without damage, profiled gripping surfaces and a burner hole take flat and round material.
• Stripping holes for conductors of 0.75 to 1.5 mm² and for 2.5 mm², plus a crimping die for wire end ferrules of 0.5 to 2.5 mm².
• Cable shears with induction hardened precision cutting edges for copper and aluminium cable up to 5 x 2.5 mm² or 15 mm dia.
• Integrated opening spring with a locking pawl keeps the cutting edges closed while the other functions stay available.
• Screwed joint for precise, backlash free action, plus Comfort grips made of three ergonomic components with two KNIPEXtend interfaces.

Version

At Knipex the suffix SB stands for the self-service pack on a blister card. Technically the pliers correspond to the 13 92 200 version, only the packaging differs. The pronounced outer edge on the gripping surfaces works flush-mounted boxes and deburrs cable entry holes, while the slim shape keeps access open at densely packed terminals.

Areas of use

Electrical installation in residential and commercial buildings, control cabinet and plant construction, service and maintenance, as well as retail sales from a display rail.
