Crimping pliers for shielded and unshielded RJ45 Western plugs, burnished, 190 mm, blister card - Knipex 97 51 13 SB

When assembling patch cables and network outlets the crimp has to come out the same on all eight contacts, otherwise the link fails the measurement. The crimping pliers of this series press shielded and unshielded Western plugs RJ45 (8P8C) with a parallel movement, they are 190 mm long and the 97 51 13 SB version is supplied ready for sale on a blister card.

Benefits

• For data cables in telecommunication and networks, designed for shielded and unshielded Western plugs RJ45 (8P8C).
• Adjustable retaining bracket, so all common RJ45 plugs with closed and non-closed housings fit into the seat.
• Separate crimping die for strain relief (cable clip), the cable jacket is secured in the same working step.
• High-quality blades for quick cutting and stripping of CAT cables, a second tool is not needed.
• Precise crimping process thanks to parallel crimping, the unlockable ratchet mechanism secures repetitive, high crimping quality.
• Force magnified by lever action for fatigue-free working, even when many plugs are terminated one after another.

Version and packaging

The pliers are burnished, the handles carry multi-component grips and the tool length is 190 mm. The suffix SB stands for the self-service blister, this version comes on a blister card and is therefore prepared for wall display in retail. Technically it matches the version without a blister, only the packaging differs.

Areas of use

Network and telecommunication technology, patch cable assembly, installation and service on structured cabling. Because cutting, stripping and crimping come together in one tool, the pliers suit work on site.

Manufacturer data

The manufacturer does not run a separate data sheet page for the blister version 97 51 13 SB. Individual values for weight, dimensions, EAN and capacity are therefore deliberately not quoted here, the description relies on the design of the series and on the catalogue name of this article.
