Metal cap for GSFR guide kit, SFR-B solder feeder for robot - JBC 0029948
Original metal cap from the GSFR guide kit of the JBC SFR-B solder feeder. According to the JBC parts list the same part in all kits with and without wire perforation, for 0.4 to 1.6 mm wire.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
A lost or deformed small part can stop a soldering robot. Metal cap 0029948 is a component of the JBC GSFR guide kits and can be reordered individually instead of replacing the complete guide kit.
The GSFR guide kit is used in the JBC SFR-B Solder Feeder for Robot and is selected according to the solder wire diameter. The version with solder wire perforation (GSFR..V..-B) is available for 0.8, 1.0, 1.2, 1.5 and 1.6 mm wire, the version without perforation (GSFR..D..-B) for 0.4 to 1.6 mm. According to the JBC exploded views, metal cap 0029948 is the same part in both versions and for all wire diameters.
Benefits
- Original spare part according to the JBC exploded view of the GSFR guide kits
- Fits kits with and without solder wire perforation
- For all wire diameters from 0.4 to 1.6 mm
- Available individually, no new guide kit required
- ESD-safe version according to catalogue
Applications
- Maintenance of JBC SFR-B solder feeders on HA245, HA470, TRA245 and TRA470
- Replacement of a lost or damaged metal cap
- Spare parts stock for automated soldering lines
Technical data
| Type | Metal cap |
|---|---|
| Compatible with | JBC guide kits GSFR..V..-B (with perforation) and GSFR..D..-B (without perforation) |
| Device | JBC SFR-B Solder Feeder for Robot |
| Wire diameters of the kits | 0.4 to 1.6 mm |
| Weight | 0.01 kg |
| Sales unit | 1 piece |
| ESD | yes |
| Manufacturer | JBC |
| Manufacturer part number | 0029948 |
| Manufacturer Nr. | 0029948 |
| HS-Code | 85159080 |
| GPSR manufacturer information | JBC Soldering SL Ramón y Cajal 3 ES-08750 Molins De Rei www.jbctools.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Spain |
| ESD version | ESD (antistatic) |
