LED magnifier luminaire TEVISIO TVD 750/940/DM, 13 W, 3.5 + 8 dpt., long arm - Waldmann 113714000-00800678
LED magnifier luminaire with a long arm (A = 484 mm, B = 500 mm), a Ø 160 mm glass lens of 3.5 dioptres and a bonded additional lens of 8 dioptres. The long arm also reaches deep work surfaces and assembly fixtures. 750 lm at approx. 13 W and Ra above 90.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Deep workbenches and fixtures call for reach, fine defect patterns call for magnification. The TEVISIO TVD 750/940/DM with long arm (A = 484 mm, B = 500 mm) combines both and delivers 750 lm at approx. 13 W through a glass lens of 3.5 dioptres and a bonded additional lens of 8 dioptres.
Benefits in use
- Long arm with A = 484 mm and B = 500 mm also covers deep work surfaces and fixtures.
- Bonded additional lens with 8 dioptres provides 3.00x magnification in the partial field, the main field stays at 1.88x.
- 750 lm at approx. 13 W result in around 57 lm/W with homogeneous light distribution and no hotspots.
- Ra > 90 and R9 > 50 keep colour assessment on part and surface dependable.
- Film button in the luminaire head for On/Off, dimming and visualizer function with segment switching.
- Tool-free lens exchange via the bayonet ring, net weight approx. 3 kg.
Areas of application
- Assembly and testing workplaces in electronics manufacturing
- Watchmaker and goldsmith workplaces
- Laboratory and dental workstations
- Quality control in metal working and in restoration
Technical data
| Series | TEVISIO |
|---|---|
| Model | TVD 750/940/DM |
| Manufacturer number | 113714000-00800678 |
| Lamp | LED, permanently installed |
| Power consumption | approx. 13 W |
| Luminous flux | 750 lm |
| Luminous efficacy | approx. 57 lm/W |
| Colour temperature | 4000 K, neutral white |
| Colour rendering | Ra > 90, R9 > 50 |
| Glare reduction | satinised plastic screen |
| Lens | glass lens Ø 160 mm, 3.5 dpt. |
| Additional lens | bonded additional lens 8 dioptres |
| Magnification | 1.88x at 3.5 dpt., 3.00x within the 8 dioptre additional lens |
| Head joint | 3D head joint |
| Arm | spring-relieved, A = 484 mm, B = 500 mm |
| Operation | film button in the luminaire head for On/Off, dimming and visualizer function (segment switching) |
| Operating device | electronic plug-in ballast |
| Connected load | 100-240 V, AC, 50/60 Hz |
| Connection lead | approx. 3 m with mains power connector, connector type CEE 7/16 (Euro connector), BS1363 and NEMA 1-15/P |
| Degree of protection | IP20 |
| Protection class | II |
| Materials | colourless anodised aluminium with black special-purpose plastic |
| Weight | approx. 3 kg |
| ESD version | no |
| Origin | Germany |
| Manufacturer | Waldmann |
| Manufacturer Nr. | 113714000-00800678 |
| EAN | 4013330044091 |
| HS-Code | 94054239 |
| GPSR manufacturer information | WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen www.waldmann.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Colour | Black |
| Farbe | schwarz |
| Luminous flux (lumen) | 750 lm |
| Power (W) | 13 W |
| Colour rendering (Ra) | Ra 90 |
| Mounting type | Table clamp |
| Magnification (dioptres) | 8 dpt |
| Operating voltage | 100-240 V |
| Magnification max (x) | 1.88 |
| Protection class (IP) | IP20 |
Scope of delivery
The luminaire is delivered with an approx. 3 m connection lead and a mains power connector of type CEE 7/16 (Euro connector), BS1363 and NEMA 1-15/P. It is fastened to the workplace with a screw-on flange or a base. Waldmann offers table clamps for panel thicknesses from 0 to 165 mm, a wall bracket and a plastic lens Ø 160 mm with 6 dpt. for 2.50x magnification as accessories.
Manufactured by Waldmann in Villingen-Schwenningen, Germany. The luminaire carries the CE marking of the manufacturer.
