Bicycle Set Torque 1 bicycle torque set with Click-Torque A 5, 1/4", 2.5-25 Nm, 16 pieces - Wera 05004180001
Click-Torque A 5 torque wrench (2.5-25 Nm) with 4 sockets and 11 bit sockets for the most common screw profiles on road bikes, mountain bikes and e-bikes. Precision of ±4 % as per DIN EN ISO 6789-1 protects sensitive components.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Stems, seat posts and brakes on bicycles require precisely applied tightening torques, otherwise sensitive components suffer. This 16-piece set combines the Click-Torque A 5 wrench with 2.5 to 25 Nm and an accuracy of ±4 % with matching sockets and bit sockets for road bikes, mountain bikes and e-bikes.
Benefits
- Easy setting of the torque value with audible and tactile click at each scale value (click 1), readable on main and fine scale.
- Audible and tactile trigger when the set value is reached (click 2).
- Reversible ratchet with 45 teeth, for clockwise torque control.
- Bit sockets with holding function: a spring-loaded ball clamps the hexagon socket screw, even in hard-to-reach areas.
- Take it easy tool finder with colour coding by size.
- Compact storage in a textile box that protects surfaces and keeps weight low.
Applications
Assembly and maintenance of road bikes, mountain bikes and e-bikes in the bike workshop and on the road, wherever screws must be tightened to a specified torque.
Standards and safety
The torque wrench works with a precision of ±4 % as per DIN EN ISO 6789-1:2017-07.
Technical data
| Torque range | 2.5-25 Nm |
|---|---|
| Accuracy | ±4 % as per DIN EN ISO 6789-1:2017-07 |
| Drive | 1/4" |
| Set contents | 1 x Click-Torque A 5 1/4" 2.5-25 Nm, 4 x Zyklop socket 8790 HMA 10, 13, 14, 15 x 23 mm, 4 x TORX bit socket 8767 A TX 10, 20, 25, 30 x 28 mm, 7 x hexagon bit socket 8740 A HF 3, 4, 5, 6, 8 x 28 mm and 5 and 6 x 100 mm, 1 x hook and loop strip 240 x 50 mm |
| Size | 335 x 110 x 65 mm |
| Weight | 1180 g |
| Manufacturer | Wera |
| Manufacturer Nr. | 05004180001 |
| EAN | 4013288207685 |
| HS-Code | 82079030 |
| GPSR manufacturer information | WERA Werkzeuge GmbH Korzerter Strasse 21-25 DE-42349 Wuppertal-Cronenberg www.wera.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Czechia |
| Height | 65 mm |
| Width | 110 mm |
| Norm | DIN EN ISO 6789-1 |
| Min torque (Nm) | 2.5 |
| Max torque (Nm) | 25 |
