410 i VDE B RA VDE-insulated T-handle adapter screwdriver with ratchet function, 3/8" x 130 mm - Wera 05005122001
VDE-insulated T-handle with ratchet mechanism and 3/8" square drive for Wera Zyklop VDE bit sockets and sockets, blade length 130 mm. Individually tested to IEC 60900 at 10,000 V for work up to 1,000 V, the T-handle transmits high tightening and loosening torques.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
For electricians working live with 3/8" VDE sockets, this T-handle screwdriver combines a ratchet with the power transmission of a T-handle. The fine-toothed ratchet mechanism with a 4.5° return angle allows fast screwdriving, and the tool is individually tested at 10,000 V for safe working up to 1,000 V.
Benefits
- Fine-toothed ratchet mechanism integrated in the handle with a small return angle of 4.5° for fast and powerful work.
- Rotating sleeve with recesses: finger force creates resistance, so the ratchet works even when the screw turns easily.
- Square drive with integrated ball lock for a secure fit and quick change of the socket.
- Reversing lever for an easy change between clockwise and counterclockwise operation.
- T-handle with softly rounded finger recesses for high tightening and loosening torques, the coated handle protects sensitive surfaces.
Applications
Electrical installation, control cabinet construction and maintenance of low-voltage systems. For use only with 3/8" VDE bit sockets and sockets from the Wera Zyklop VDE series 8740, 8760, 8767 and 8790.
Standards and safety
Individually tested tool to IEC 60900 at 10,000 V for safe working at the approved voltage of 1,000 V.
Technical data
| Mount | 3/8" square with ball lock |
|---|---|
| Blade length | 130 mm (5 1/8") |
| Handle length | 49 mm |
| Handle diameter | 99 mm |
| Return angle | 4.5° |
| Insulation | VDE, individually tested at 10,000 V, approved up to 1,000 V |
| Size | 185 x 105 x 30 mm |
| Weight | 233 g |
| Manufacturer | Wera |
| Manufacturer Nr. | 05005122001 |
| HS-Code | 82054000 |
| GPSR manufacturer information | WERA Werkzeuge GmbH Korzerter Strasse 21-25 DE-42349 Wuppertal-Cronenberg www.wera.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Czechia |
| Height | 30 mm |
| Width | 105 mm |
| Norm | DIN EN IEC 60900 |
| Certification | IEC 60900 |
| Overall length [mm] | 185 |
