Kraftform Kompakt 400 RA Imperial Set 1, 17 pieces, T-handle bitholding screwdriver with ratchet and 89 mm bits - Wera 05057473001

Wera ✓ Original product Brand new Made in Czechia

416 RA T-handle bitholding screwdriver with fine-tooth ratchet (80 teeth, 4.5° return angle) and Rapidaptor quick-release chuck plus 16 tough bits of 89 mm length, hexagon socket in imperial sizes. In a 150 x 130 x 50 mm textile box.

Net
€93.40
excl. VAT
Item WR-05057473001
Manufacturer no. 05057473001
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Driving imperial hexagon, Square-Plus or TORX screws by hand without repositioning calls for a ratchet built right into the handle. The Kraftform Kompakt 400 RA Imperial Set 1 combines the 416 RA T-handle bitholding screwdriver with 16 long 89 mm bits in a textile box.

Benefits

  • Integrated fine-tooth ratchet: 80 teeth and a 4.5° return angle accelerate screwdriving without having to reposition the tool.
  • Ratchet mechanism fully embedded in the handle, reversing lever for clockwise/counterclockwise change in one-hand operation.
  • Rapidaptor with fast-rotating sleeve: Rapid-in without moving the sleeve, Rapid-out by spring mechanism.
  • Ergonomic 2-component T-handle with finger recesses for high power transmission and fatigue-free working.
  • Long 89 mm bits for recessed screws.

Applications

Assembly and maintenance on machinery, furniture and equipment with imperial and Square-Plus screws, especially where manual force and speed are needed.

Standards and safety

The bit holder takes bits with 1/4" external hexagon drive as per DIN ISO 1173-C 6.3 and E 6.3.

Technical data

Number of pieces17
T-handle bitholding screwdriver 416 RA1 x 1/4" x 45 mm, with ratchet and Rapidaptor
Ratchet80 teeth, return angle 4.5°
Phillips Z bits 851/41 x PH 2, 1 x PH 3, each 89 mm
TORX Z bits 867/41 each TX 10, TX 15, TX 20, TX 25, TX 30, TX 40, each 89 mm
Hexagon Z bits 840/41 each 1/8", 5/32", 3/16", 7/32", 1/4", each 89 mm
Square-Plus bits 868/41 x # 2, 1 x # 3, each 89 mm
Slotted Z bit 800/41 x 1 x 5.5 x 89 mm
AccessoryHook and loop fastener strip 120 x 50 mm
Bit take-up1/4" as per DIN ISO 1173-C 6.3 and E 6.3
Size150 x 130 x 50 mm
Weight567 g
ManufacturerWera
Manufacturer Nr.05057473001
EAN4013288222930
HS-Code82079030
GPSR manufacturer informationWERA Werkzeuge GmbH Korzerter Strasse 21-25 DE-42349 Wuppertal-Cronenberg www.wera.de
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureCzechia
Height50 mm
Width130 mm
NormISO 1173
