Kraftform 7466 Imperial torque screwdriver, factory pre-set 11 in. lbs. (11-29 in. lbs.), 1/4" Rapidaptor - Wera 05074722001
Torque screwdriver from the 7400 Imperial series, factory pre-set to 11.0 in. lbs. within an 11.0-29.0 in. lbs. range. For screwdriving with the same torque and repeat accuracy, with Rapidaptor chuck for 1/4" bits and 105 mm Kraftform handle.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Where every screw has to be tightened to the same inch-pound value, the Kraftform 7466 takes setting out of the equation: it is factory pre-set to 11.0 in. lbs. and can only be adjusted with an extra tool.
Benefits
- Pre-set to the smallest scale value for constant torque and repeat accuracy.
- Value can be changed within the 11.0-29.0 in. lbs. range using the re-calibration kit 05137001001, then checked with a torque tester.
- Distinct signal when the pre-set value is reached and unlimited loosening torque.
- Rapidaptor with chuck-all, rapid-in, self-lock and rapid-out for quick bit changes.
- Multi-component Kraftform handle with hard and soft zones for high working speeds.
Applications
Series assembly in electronics, precision engineering and equipment building with a fixed tightening torque specified in in. lbs.
Standards and safety
For bits with 1/4" external hex drive as per DIN ISO 1173-C 6.3 and E 6.3 (ISO 1173). Changing the pre-set value requires a special tool and torque test equipment.
Technical data
| Article | 7466 |
|---|---|
| Drive | 1/4" hex, Rapidaptor |
| Pre-set value | 11.0 in. lbs. |
| Measuring range | 11.0-29.0 in. lbs. |
| Handle length | 105 mm |
| Overall length | 155 mm (6") |
| Size | 155 x 37 x 37 mm |
| Weight | 180 g |
| Manufacturer | Wera |
| Manufacturer Nr. | 05074722001 |
| EAN | 4013288103116 |
| HS-Code | 82054000 |
| GPSR manufacturer information | WERA Werkzeuge GmbH Korzerter Strasse 21-25 DE-42349 Wuppertal-Cronenberg www.wera.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Czechia |
| Height | 37 mm |
| Width | 37 mm |
| Norm | ISO 1173 |
| Overall length [mm] | 155 |
| Min torque (Nm) | 1.24 |
| Max torque (Nm) | 3.28 |
