Divider insert 358 x 200 mm for BLACKLINE containers, pitch from 71 mm - WEZ EP0705066

At 200 mm the divider reaches well into the container, so stacked parts cannot slip across a compartment border. The 358 x 200 mm insert subdivides a BLACKLINE container from a pitch of 71 mm upwards.

Benefits

• Format 358 x 200 mm, matched to the inner contour of the BLACKLINE containers.
• Smallest pitch 71 mm, so compartment width can follow the range of parts stored.
• Clear calculation basis, deduct 7 mm of pitch dimension for the usable size.
• At 0.1 kg the usable payload of the container stays practically unchanged.
• Original WEZ part, it extends existing BLACKLINE containers without changing the storage concept.
• Listed as an accessory for the ESD stacking containers, in line with the container equipment used in the EPA.

Technical data

Application

Typical cases are containers holding stacked sheet metal parts, housing halves or longer profiles, where a low wall no longer guides the load. When the container is only partly filled, the tall wall still keeps the compartments apart at the line.

Note on the range

The divider inserts for BLACKLINE containers are offered in several formats. This article is the 358 x 200 mm version.
