ESD swivel castor with wheel brake, 11 mm bolt hole, grey non-marking tread - A1-ESD EP0806079

Castors with a light tread leave no black marks on the shop floor, and inside an ESD protected area they still have to drain the charge. This swivel castor covers both with an electrically conductive polypropylene wheel centre and a grey, non-marking TENTEprene tread, plus a wheel brake for the parked trolley.

Benefits

• Polypropylene wheel centre, electrically conductive, so the charge drains through the castor to the floor.
• Tread in TENTEprene, a grey non-marking thermoplastic rubber, which keeps light flooring free of abrasion marks.
• Wheel brake, so the parked trolley stays at the workplace.
• Swivel head with a double ball race, the castor follows the steering input without extra pushing.
• Pressed steel housing, bright zinc plated and blue passivated, suited to continuous use in production.
• Fixing through an 11 mm bolt hole, mounted with standard screws of any length, so the frame thickness is free to choose.

Technical data

Application

The castor is used under assembly and supply trolleys, mobile frames and pedestals that are moved inside the EPA and locked at the workplace. The non-marking tread pays off wherever the floor is light in colour or is judged visually, for example in test rooms and assembly areas. The range covers further wheel diameters.
