ESD personnel tester EPA-RESIST 7000 with RFID and touch display - A1-ESD EP0206076

The EPA-RESIST 7000 controls and documents the entry test at the EPA. RFID links test profiles and results to each person, so every employee gains traceable access quickly after passing the test.

Main functions

• 7-inch colour touch display with intuitive operation and German/English language selection
• Person identification via RFID, assignment of test profiles and results
• Testing of wrist strap and footwear plus automatic shoe-to-shoe test
• Additional functional tests for gloves and lab coat
• Special test function for vulnerable persons through a voltage-free body test (pregnant persons, persons with active implants)
• Measurement of temperature and relative humidity

Technical data

• Display: 7-inch colour touch display
• Processor: 32 bit for fast and precise measurements
• Measurement voltages selectable: 33 V, 50 V or 100 V
• Access control: 3 freely configurable relays
• Interfaces: LAN for web interface, USB for software updates (integrated bootloader)
• Storage of test results in the device
• Connection for automated on-site calibration without removal
• Power supply 24 V with mains cable
• Weight: approx. 5.0 kg

Scope of delivery

• EPA-RESIST 7000
• Mounting console for wall or desk mounting
• 24 V power supply with mains cable
• Foot electrode EP0206062
• Relay output connection cable
• Operating manual and calibration certificate

Standards and compliance

Verifies ESD personnel grounding to IEC 61340-5-1: wrist strap per IEC 61340-4-6, footwear and person/footwear system per IEC 61340-4-5, lab coat per IEC 61340-4-9 and gloves per IEC TR 61340-5-2.
