Metal-In ESD shielding bag with flap and adhesive strip, 420 x 580 mm

This shielding bag in 420 x 580 mm protects PCB panels, backplanes and bulky assemblies from electrostatic fields and discharges during transport and storage. The metallisation sits inside the laminate (Metal-In) while the bag stays transparent. A flap with self-adhesive strip closes it.

Benefits

• Shielding to EN 61340-5-1 and EN 61340-5-3, suitable as packaging inside and outside the EPA
• Surface resistance inside and outside below 10E11 Ohm, so no hazardous charge builds up on the film
• Flap with self-adhesive strip: close the bag right at the workstation, no heat sealer needed
• Transparent film, contents and accompanying papers can be identified without opening
• Printed ESD warning symbol marks the contents as electrostatic sensitive

Applications

420 x 580 mm is the largest format in this range. It takes PCB panels before depaneling, long backplanes and bulky assemblies, for example when returning units for repair. Yellow ESD labels with warning text can be added for extra marking. The range is available in further formats.
