Extraction arm DN75, aluminium, 3 joints, 1620 mm, red, table mounting - Alsident 75-9065-1-4

This extraction arm from the aluminium version of Alsident System 75 removes vapours, fumes and particles at the point of origin, before they spread into the room air. In the machinery industry it captures fumes and vapours at assembly and test stations with large work surfaces. Fitted on a table bracket or U-profile, the arm sits right at the workstation, and its 1620 mm reach extends to distant positions on large work surfaces. Anodised aluminium tubes and red polypropylene (PP) joints are designed for tasks without special demands on chemical resistance or static dissipation.

Benefits

• Self-supporting design: threaded rods and springs sit inside the arm, so the hood is easy to position at the source
• Dismantled without tools in a few steps, maintenance is limited to cleaning as needed
• Anodised aluminium tubes, impact-resistant PP plastic parts, threaded rods and springs in acid-resistant stainless steel AISI 316L
• Table mounting keeps the arm within immediate reach at the workstation

Specifications

Applications

• Machinery industry
• Laser technology
• Food industry
• School and university science rooms

Compatibility and scope of delivery

• Matching System 75 hoods: 1-7524-4 (round Ø200), 1-7528-4 (round Ø280), 1-7535-4 (round Ø385), 1-753324-4 (330 x 240 mm), 1-7526-4 (suction nozzle 250 mm)
• Bracket: table bracket 2-7510 or U-profile 30-75-5
• Guard grille 5-17, reducing socket 4-8075 (80/75 mm) or 4-10075 (100/75 mm) to the exhaust duct
• Scope of delivery: extraction arm without hood and bracket, order both separately
