Light smoke and gases rise across a wide area and escape a small nozzle. This square hood offers a 420 x 320 mm capture face over the source and mounts on a DN 75 extraction arm via its 75 mm socket. The transparent PETG keeps the workpiece in view, while the reinforced edge keeps the hood rigid during repositioning.
Extraction hood square 420 x 320 mm transparent DN 75 - Alsident 1-754232-4
ALSIDENT
Original product
Net price (excl. VAT)
€155.78
Item
WL19385
Manufacturer no.
1-754232-4
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.1-754232-4
ConditionNew
Article
WL19385
Frequently Bought Together
-
This Item:
€155.78
-
Round hood DN50 diameter 200 mm white - Alsident 1-5024-5
€120.79
-
Reducing sleeve 80 to 50 mm System 50 polypropylene white - Alsident 4-8050
€27.43
Total price
Where solder fume, adhesive vapour or solvent gases are released over a larger area, point extraction is not enough. The Alsident 1-754232-4 is a square extraction hood of 420 x 320 mm that widens the capture zone and fits onto DN 75 series extraction arms through its 75 mm pipe socket.
Benefits
- Capture face of 420 x 320 mm for light smoke and gases from wide sources
- Transparent PETG hood keeps a clear view of the workpiece while working
- Edge reinforcement adds stability for daily repositioning of the hood
- Higher capture performance when the hood is placed vertically above the source
- PETG is solvent resistant and the aluminium pipe socket is anodised to 10 μ
Technical data
| Item number | WL19385 |
| Model | 1-754232-4 |
| Manufacturer | Alsident |
| Manufacturer item number | 1-754232-4 |
| Width | 420 mm |
| Length | 320 mm |
| Diameter of tube | 75 mm |
| Material | Transparent PETG hood, solvent resistant, anodised aluminium pipe socket with 10 μ layer thickness |
| Colour | Red |
| Order unit | Piece |
| Weight | 0.1 kg |
Applications
Capture of solder fume at hand soldering benches, of vapours from bonding and potting, and of gases above open containers and small laboratory setups. The square shape suits rectangular work surfaces and assembly stations.
Compatibility and scope of delivery
Fits Alsident extraction arms of the DN 75 series with a 75 mm connection. Supplied as one extraction hood in red with pipe socket. Extraction arm, base and fan are not included.
| Manufacturer Nr. | 1-754232-4 |
|---|---|
| Manufacturer | Alsident |
| Weight | 0.100000 |
| Colour | Red |
| GPSR manufacturer information | Alsident system A/S Finlandsvej 10 DK-8450 Hammel www.alsident.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
