Telescopic extraction arm DN75, 2 joints, 1300-1900 mm, white, ceiling mounting - Alsident 900-1900-3

Name: Telescopic extraction arm DN75, 2 joints, 1300-1900 mm, white, ceiling mounting - Alsident 900-1900-3
Brand: Alsident
SKU: AL-900-1900-3
Price: 1620.66 EUR
Availability: InStock

Alsident ✓ Original product Brand new Made in Denmark

Telescopic extraction arm DN75 for ceiling mounting with 1300 to 1900 mm reach for workstations in the middle of the room. Anodised aluminium, 2 white PP joints, 80 to 180 m³/h.

Net

€1,620.66

excl. VAT

Item AL-900-1900-3

Manufacturer no. 900-1900-3

Question about this item

Datasheet (PDF) 4 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

With 1300-1900 mm reach, the long ceiling version is designed for workstations standing freely in the room and serves a stationary source from above without taking up space on the bench or wall.

Benefits

Telescopic tube slides together steplessly and is self-supporting
Integrated damper, out of the airflow when open
Threaded rods, springs and thumb screws made of acid-resistant stainless steel AISI 316L
Tool-free disassembly for cleaning
Maintenance-free O-rings

Specifications

Applications

Free-standing workstations in labs and production
Decanting and dosing in pharmacies
Weighing and decanting
Applications without special requirements for chemical resistance or conductivity

Compatibility and scope of delivery

Hoods from Alsident System 75 AL, e.g. suction nozzle 1-7525
Wall bracket 2-100-203 or base boxes 2-100-500 to 2-100-2500 from System 100
Protective grid 5-17 and reducing sleeve 4-100125 as accessories
Arm, hood and bracket are ordered separately

Technical data

Manufacturer part no.	900-1900-3
Type	Telescopic extraction arm, System 75 Telescope AL
Tube diameter	Ø75 mm (hood) / Ø100 mm (bracket)
Reach	1300-1900 mm
Joints	2
Mounting	Ceiling mounting
Tube material	Anodised aluminium, 10 µm coating
Joint material	Polypropylene (PP)
Joint colour	White
Airflow	80 to 180 m³/h, nominal 140 m³/h
Air temperature	-15 °C to +90 °C
RoHS	All components compliant
Sales unit	1 piece
Weight	2 kg
Manufacturer	Alsident
Manufacturer Nr.	900-1900-3
HS-Code	84219990
GPSR manufacturer information	Alsident system A/S Finlandsvej 10 DK-8450 Hammel www.alsident.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Denmark
Colour	White
Mounting type	Ceiling mounting
Air flow [m³/h]	140
Compatible with	Alsident System 75
