Ultrasonic Bath 9.5 L with Flat Tank, 35 kHz - Bandelin Sonorex Digitec DT 1028 F
Powerful flat-tank ultrasonic bath with 9.5 L capacity and 35 kHz for rapid degassing and sample preparation in the lab. The wide, shallow tank holds several flasks at once, with SweepTec ensuring even sonication of every sample.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Sonorex Digitec DT 1028 F is a powerful laboratory ultrasonic bath with a flat tank for rapid degassing and sample preparation. At 35 kHz and 1280 W peak power it sonicates larger sample series evenly, regardless of the size or arrangement of the vessels. The sonication time is set via a wipe-clean keypad and shown on the display.
Benefits
- Wide flat tank with 9.5 L capacity for several flasks at once
- 1280 W HF peak power for fast, vigorous degassing
- SweepTec suppresses standing waves for uniform sonication
- Wipe-clean keypad with remaining-time display
- Retaining clips stop flasks from tipping or floating up
- Corrosion-resistant V2A stainless steel tank
Applications
The DT 1028 F degasses solvents and HPLC eluents in the lab, prepares samples and gently homogenizes sensitive preparations. The wide flat tank is ideal for sonicating several low-fill vessels in parallel.
Matching insert baskets, lids and cleaning concentrates are available as Bandelin accessories.
Technical data
| Order no. | 13243 |
|---|---|
| Capacity | 9.5 L |
| Working volume | 5.8 L |
| Inner dimensions (L×W×D) | 500 × 300 × 65 mm |
| Outer dimensions (L×W×H) | 535 × 325 × 205 mm |
| Ultrasonic frequency | 35 kHz |
| HF peak power | 1280 W |
| HF nominal power | 320 W |
| Tank material | Stainless steel V2A (1.4301) |
| Drain | Ball valve G ½, left side |
| Weight | 15.973 kg |
| Manufacturer | Bandelin |
| Manufacturer Nr. | 13243 |
| HS-Code | 84798997 |
| GPSR manufacturer information | BANDELIN electronic GmbH & Co. KG, Heinrichstraße 3-4, DE-12207 Berlin, bandelin.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| ESD version | TEC |
| Volumen (l) | 9.5 |
