Workpiece Pallet WT 2/LS 240x400, EPA-Compliant - Bosch Rexroth 3842562352
Datasheet (PDF)
The product may differ from the illustration
Workpiece pallet for toothed belt, flat belt and flat top chain conveyors, rated for use in electrostatic protected areas (EPA). Dimensions 400 x 240 mm, payload up to 20 kg, process force Fy up to 500 N. Supplied fully assembled with magnetic cover and all mounting elements.

Workpiece Pallet WT 2/LS 240x400, EPA-Compliant - Bosch Rexroth 3842562352

BOSCH REXROTH Original product
Net price (excl. VAT)
€1,719.22
Excl. 19% VAT , excl. Shipping Cost
Available Fast shipping
Item BRR-3842562352
Manufacturer no. 3842562352
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842562352
Country of originGermany
Customs tariff number84313900
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842562352

The Bosch Rexroth WT 2/LS 240x400 workpiece pallet is designed for toothed belt, flat belt and flat top chain transfer systems and meets the requirements of electrostatic protected areas (EPA). It carries loads up to 20 kg and transmits process forces up to 500 N in the Y direction. The scope of delivery includes carrying plates, frame modules, connection elements and positioning bushings; the pallet is delivered fully assembled and individually packed with a magnetic cover.

  • Payload up to 20 kg at room temperature (rated force)
  • Process force Fy up to 500 N; Fz variable: Fz = 100 N plus remaining available load capacity
  • EPA-suitable for ESD-sensitive production environments
  • 1 magnetic row for reliable positioning on the conveyor
  • Fully assembled and ready to install

Technical data

ParameterValue
Workpiece pallet length lWT400 mm
Workpiece pallet width bWT240 mm
Length [l]153 mm
Dimension [a]9.31 mm
Dimension [b]328 mm
Dimension h114.45 mm
Dimension [c]29.45 mm
Dimension [d]43.45 mm
Number [kk6]1x
Number [M5]1x
Magnetic rows1
Force F46 N
Process force Fx0 N
Process force Fy500 N
Process force FzFz = 100 N plus remaining available load capacity
Max. payload20 kg
Workpiece pallet weight mWT4.98 kg
Weight (catalogue)4.81 kg
Delivery stateAssembled, individually packed with magnetic cover
Scope of deliveryCarrying plates, frame modules, connection elements, positioning bushings
More Information
Manufacturer Nr. 3842562352
Manufacturer Bosch Rexroth
Country of Manufacture Germany
Weight 0.100000
HS-Code 84313900
GPSR manufacturer information Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticity Original product
Condition of article New
Download
File Icon Bosch Rexroth. Katalog Mechanik-Grundelemente (de) (30.56 MB)
File Icon Bosch Rexroth. TSplus Modular Conveyors for Flexible Manufacturing (en) (12.02 MB)
File Icon Bosch Rexroth. Catalog Basic Mechanic Elements (en) (30.55 MB)
File Icon Bosch Rexroth. Aluminum Structural Framing System (en) (29.62 MB)
File Icon Bosch Rexroth. Transfersystem TS 5 (de) (40.69 MB)
File Icon Bosch Rexroth. Transfer system TS 5 (en) (43.75 MB)
File Icon Bosch Rexroth Éléments mécaniques de base (fr) (36.36 MB)
