Plate Holder Profile Slot 8 QUICK 0° for Panel Elements 2-6 mm - Bosch Rexroth 3842564671
Datasheet (PDF)
The product may differ from the illustration
Plate holder for panel elements with a thickness of 2 to 6 mm in profile slot 8. Enables virtually gap-free surface mounting in front of the profile and allows subsequent installation in closed frame constructions. An optional headless setscrew M5x10 provides protection against disassembly per Machinery Directive 2006/42/EC.

Plate Holder Profile Slot 8 QUICK 0° for Panel Elements 2-6 mm - Bosch Rexroth 3842564671

BOSCH REXROTH Original product
Net price (excl. VAT)
€2.14
Excl. 19% VAT , excl. Shipping Cost
Available Fast shipping
Item BRR-3842564671
Manufacturer no. 3842564671
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842564671
Country of originItaly
Customs tariff number39269097
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842564671

The plate holder for profile slot 8 secures panel elements with a thickness of 2 to 6 mm flush in front of the profile with virtually no visible gap. QUICK mounting allows fast positioning, and the design supports subsequent installation in already-closed frame constructions. An optional headless setscrew M5x10 locks the assembly against unintended removal in compliance with Machinery Directive 2006/42/EC.

  • Virtually gap-free mounting of surface elements directly in front of the profile
  • Subsequent installation in closed frame constructions without disassembly
  • Disassembly protection via headless setscrew M5x10 (Machinery Directive 2006/42/EC)
  • POM material, signal gray RAL 7004

Technical data

PropertyValue
Profile slot8
Panel thickness s min2 mm
Panel thickness s max6 mm
MaterialPOM
ColorSignal gray RAL 7004
Weight0.008 kg
Packaging unit10 pieces
Recommended accessoryHeadless setscrew M5x10
More Information
Manufacturer Nr. 3842564671
Manufacturer Bosch Rexroth
Country of Manufacture Italy
Weight 0.008000
HS-Code 39269097
GPSR manufacturer information Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticity Original product
Condition of article New
