Plate Holder N10 QUICK 0° for Panel Elements 2-6 mm - Bosch Rexroth 3842564670
Datasheet (PDF)
The product may differ from the illustration
POM plate holder for virtually gap-free mounting of panel elements (2-6 mm thick) in profile slot N10. Suitable for subsequent installation in closed frame constructions. Tamper protection via headless setscrew M5x10 available (Machinery Directive 2006/42/EC).

Plate Holder N10 QUICK 0° for Panel Elements 2-6 mm - Bosch Rexroth 3842564670

BOSCH REXROTH Original product
Net price (excl. VAT)
€2.36
Excl. 19% VAT , excl. Shipping Cost
Available Fast shipping
Item BRR-3842564670
Manufacturer no. 3842564670
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842564670
Country of originItaly
Customs tariff number39269097
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842564670

The plate holder N10 QUICK 0° secures panel elements from 2 to 6 mm thickness flush in front of the profile, achieving a virtually gap-free surface finish. Its design allows insertion into closed frame constructions after the fact, and an optional headless setscrew M5x10 locks the holder against removal in compliance with Machinery Directive 2006/42/EC.

  • Virtually gap-free surface finish through flush panel mounting
  • Covers panel thicknesses from 2 to 6 mm without changing holder type
  • Subsequent installation in closed frame constructions possible
  • Tamper protection with headless setscrew M5x10 (recommended accessory)
  • Lightweight POM component at 0.008 kg - negligible structural weight

Technical data

FeatureValue
Profile slotN10
Panel thickness s min2 mm
Panel thickness s max6 mm
Angle0°
MaterialPOM
ColorSignal gray RAL 7004
Recommended accessoriesHeadless setscrew M5x10
Packaging unit10 pieces
Weight0.008 kg
More Information
Manufacturer Nr. 3842564670
Manufacturer Bosch Rexroth
Country of Manufacture Italy
Weight 0.008000
HS-Code 39269097
GPSR manufacturer information Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticity Original product
Condition of article New
