Rotary Unit DE 2 BG 2, 128 kg Capacity, 5-6 bar Compressed Air - Bosch Rexroth 3842998872
Datasheet (PDF)
The product may differ from the illustration
Pneumatic rotary unit for horizontal rotation and transport of workpiece carriers in assembly transfer systems. Handles branch-offs and crossings even for heavy pallets up to 128 kg. Available in track widths of 480 mm and 640 mm, supplied ready to install including supports.

Rotary Unit DE 2 BG 2, 128 kg Capacity, 5-6 bar Compressed Air - Bosch Rexroth 3842998872

BOSCH REXROTH Original product
Net price (excl. VAT)
€15,761.54
Excl. 19% VAT , excl. Shipping Cost
Available Fast shipping
Item BRR-3842998872
Manufacturer no. 3842998872
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842998872
Country of originGermany
Customs tariff number84313900
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842998872

The Bosch Rexroth Rotary Unit DE 2 BG 2 is a transfer-system module designed for the horizontal rotation and transport of workpiece carriers. It enables branch-offs and crossings in the conveyor layout, even when handling heavy workpiece pallets up to 128 kg total weight, and is available in two track widths for flexible integration.

  • Load capacity up to 128 kg - suitable for heavy workpiece pallets
  • Rotation times: 90° in 4 s, 180° in 7 s, 270° in 10 s
  • Pneumatic straight connection 6 mm, operating pressure 5-6 bar
  • Transportation height H: 585 to 1400 mm
  • Ready to install including supports; optional: protective covers assembled

Technical data

ParameterValue
Track width in direction of transport [b]480 mm / 640 mm
Length in direction of transport [lT]480 mm / 640 mm
Belt section length [L]818 mm / 695 mm
Diameter without protective cover [D1]980 mm
Diameter with protective cover [D2]996 mm
Transportation height [H]585 - 1400 mm
Rotation time 90°4 s
Rotation time 180°7 s
Rotation time 270°10 s
Pneumatic straight connection6 mm
Required compressed air [pmin]5 bar
Required compressed air [pmax]6 bar
Max. workpiece pallet total weight [mG]128 kg
Weightapprox. 0.1 kg (per catalogue; verify with manufacturer)
DeliveryReady to install incl. supports; optional: protective covers assembled
More Information
Manufacturer Nr. 3842998872
Manufacturer Bosch Rexroth
Country of Manufacture Germany
Weight 0.100000
HS-Code 84313900
GPSR manufacturer information Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticity Original product
Condition of article New
Download
File Icon Bosch Rexroth. Katalog Mechanik-Grundelemente (de) (30.56 MB)
File Icon Bosch Rexroth. TSplus Modular Conveyors for Flexible Manufacturing (en) (12.02 MB)
File Icon Bosch Rexroth. Catalog Basic Mechanic Elements (en) (30.55 MB)
File Icon Bosch Rexroth. Aluminum Structural Framing System (en) (29.62 MB)
File Icon Bosch Rexroth. Transfersystem TS 5 (de) (40.69 MB)
File Icon Bosch Rexroth. Transfer system TS 5 (en) (43.75 MB)
File Icon Bosch Rexroth Éléments mécaniques de base (fr) (36.36 MB)
