Rotary Unit DE 2 BG 5 for Workpiece Carriers up to 240 kg - Bosch Rexroth 3842998875
Datasheet (PDF)
The product may differ from the illustration
Pneumatic rotary unit for horizontal rotation and transport of workpiece carriers up to 240 kg in transfer assembly systems, size BG 5. Enables branch-offs and crossings in conveyor layouts. Available in three track widths (800, 1040 and 1200 mm), ready to install including supports.

Rotary Unit DE 2 BG 5 for Workpiece Carriers up to 240 kg - Bosch Rexroth 3842998875

BOSCH REXROTH Original product
Net price (excl. VAT)
€21,823.67
Excl. 19% VAT , excl. Shipping Cost
Available Fast shipping
Item BRR-3842998875
Manufacturer no. 3842998875
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842998875
Country of originGermany
Customs tariff number84313900
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842998875
Frequently Bought Together
Total price

The rotary unit DE 2 in size BG 5 is a module for horizontal rotation and onward transport of workpiece carriers in automated assembly lines. It allows branch-offs and crossings even for heavy pallets up to 240 kg, and is supplied ready to install including supports.

  • Load capacity up to 240 kg - suitable for heavy workpiece pallets
  • Three track widths available: 800 mm, 1040 mm and 1200 mm
  • Fast rotation: 90° in 4 s, 180° in 7 s, 270° in 10 s
  • Pneumatic connection 6 mm, operating pressure 5 to 6 bar
  • Transport height adjustable from 585 to 1400 mm
  • Ready to install with supports; protective covers optionally pre-assembled

Technical data

ParameterValue
SizeBG 5
Track width (direction of transport) b800 / 1040 / 1200 mm
Length in direction of transport lT800 / 1040 / 1200 mm
Belt section length L1646 / 1503 / 1376 mm
Outer diameter without protective cover D11860 mm
Outer diameter with protective cover D21876 mm
Transportation height H585 to 1400 mm
Max. workpiece pallet weight mG240 kg
Rotation time 90°4 s
Rotation time 180°7 s
Rotation time 270°10 s
Pneumatic connection6 mm
Pressure range pmin / pmax5 / 6 bar
Delivery conditionReady to install incl. supports; protective covers optional
Weight (catalogue figure)approx. 0.1 kg (figure likely incomplete - see notes)
More Information
Manufacturer Nr. 3842998875
Manufacturer Bosch Rexroth
Country of Manufacture Germany
Weight 0.100000
HS-Code 84313900
GPSR manufacturer information Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticity Original product
Condition of article New
