Lift Transfer Unit HQ 2/U LS, Toothed Belt Conveyor ESD-Compatible - Bosch Rexroth 3842999032

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Lift Transfer Unit HQ 2/U LS, Toothed Belt Conveyor ESD-Compatible - Bosch Rexroth 3842999032

Bosch Rexroth ✓ Original product Brand new Made in Germany

The HQ 2/U LS lift transfer unit feeds workpiece pallets between longitudinal and transverse conveyor sections in either direction. A suspended drive motor keeps the overall width within the profile envelope for installation in tight spaces, and the toothed belt conveyor is suitable for use in EPA environments. Pneumatic actuation provides two or three lift positions.

Net
€2,334.20
excl. VAT
Item BRR-3842999032
Manufacturer no. 3842999032
Save Compare
Question about this item
Datasheet (PDF) 8 documents, all under Downloads
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The HQ 2/U LS lift transfer unit transfers workpiece pallets from a longitudinal conveyor section into a transverse section - and in reverse. The suspended drive motor is positioned outside the main body so the overall width stays within the profile contour, making installation viable in very confined machine layouts. A toothed belt coupling drive is not possible due to the compact design; the integrated toothed belt conveyor is ESD-compatible for use in EPA (electrostatic protected area) environments. Reversible operation is supported.

  • Compact form factor with suspended drive motor - fits in tight installation spaces
  • Two configurations: PN 2 (top and center positions) or PN 3 (top, center, and bottom)
  • Toothed belt conveyor rated for ESD/EPA environments
  • Compatible with ST 2/... profiles (45 mm width) and ST 2/...-H profiles (50 mm width)
  • Reversible operation possible
  • Supplied fully assembled including fastening hardware, pneumatic equipment, and electrical position inquiry kit

Technical data

PropertyValue
Conveyor mediumToothed belt
ESD suitability (EPA)Yes
Pneumatic connection (straight)6 mm
Max. workpiece pallet total weight30 kg
Compressed air - min. pressure4 bar
Compressed air - max. pressure6 bar
Lift positions (PN 2)Top, center
Lift positions (PN 3)Top, center, bottom
Preferred dimensions160, 240, 320, 400, 480 mm
Compatible profilesST 2/... (45 mm width), ST 2/...-H (50 mm width)
Scope of deliveryFully assembled, fastening hardware, pneumatic equipment (PN 2 or PN 3), position inquiry kit, protective housing
Required accessoryM12x1 sensor, rated sensing range Sn = 4 mm, one per lift position
Weight0.1 kg
ManufacturerBosch Rexroth
Manufacturer Nr.3842999032
HS-Code84313900
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
