EC motor EC305, size 5, installation length 304 mm - Bosch Rexroth 0608701019

When a joint calls for the top size of the Tightening System 350, the EC305 EC motor is used. It drives size 5 spindles and, at 304 mm installation length and 6.4 kg net weight, is the largest motor of the EC302 to EC305 range. Allow for this weight when designing spindle mounts and feed units.

Benefits

• Drive for size 5, the top level of the modular spindle design
• Matched to the 5GE19 and 5GE68 planetary gearboxes
• Brushless EC motor, no carbon brush wear
• Like every motor of the range, controlled digitally by an LTS350D or LTE350D servo amplifier

Specifications

Applications

• Fastening spindles for the highest torques of the system
• Multi-spindle systems with large bolted joints
• Replacement in existing size 5 spindles

System compatibility

• Rexroth Tightening System 350, size 5
• 5GE19 or 5GE68 planetary gearboxes
• LTS350D or LTE350D servo amplifier
