Planetary gearbox 5GE19, size 5, ratio 19.3 - Bosch Rexroth 0608720058

Large bolted joints and short cycle times are not mutually exclusive. The 5GE19 planetary gearbox reduces at 19.3 to 1 and, in size 5, lets about three and a half times more speed reach the output than the 5GE68. At 154 mm it is 34 mm shorter, and its 2.9 kg net weight is 0.8 kg below the high-ratio version.

Benefits

• 19.3 reduction ratio for high output speed in the largest size
• 154 mm installation length, a shorter spindle than with the 5GE68
• Typical efficiency 0.93
• 2.9 kg net weight eases the load on spindle guide and feed

Specifications

Applications

• Size 5 spindles with cycle time targets
• Large joints with a long rundown

System compatibility

• Rexroth Tightening System 350, size 5
• EC305 EC motor
• For the highest torque: 5GE68
