ErgoSpin angle nutrunner ESA075G-G, 15 to 75 Nm, 1/2 in - Bosch Rexroth 0608841230

The ErgoSpin ESA075G-G angle nutrunner is designed for the highest torques among the ErgoSpin angle models listed here: 15 to 75 Nm on a 1/2 in square drive. Its integrated transducer captures the tightening process in the tool, with output speeds of up to 530 rpm.

The nutrunner is operated on a Rexroth tightening controller, either the CS351 compact tightening system or Tightening System 350. Tightening programs and limits are set there.

Benefits

• Working range 15 to 75 Nm: one tool for all joints within this torque window
• Angle design: output at right angles to the handle, for fastening points that are hard to reach from the front
• Integrated transducer: torque is measured directly in the tool
• Maintenance-free for 1 million full-load cycles according to the manufacturer
• Standard 1/2 in square drive for commercially available sockets

Specifications

Applications

• Safety-critical joints to VDI/VDE 2862
• Joints up to 75 Nm with 1/2 in sockets
• Assembly lines with high tightening torques applied by hand

System compatibility

• CS351 compact tightening system: controller and power unit in one housing for one nutrunner
• Rexroth Tightening System 350 with power unit and control unit
• S-... nutrunner cables for ErgoSpin handheld tools, length and connector shape to suit the workstation
