Cross Connector QV 1, Track Width 160 mm, PA 6 - Bosch Rexroth 3842521344
Datasheet (PDF)
The product may differ from the illustration
Cross connector QV 1 for joining conveyor section units in the longitudinal transport of the TS 1 transfer system. Made of polyamide PA 6 for a track width of 160 mm. A section-unit component that sets the track spacing.

Cross Connector QV 1, Track Width 160 mm, PA 6 - Bosch Rexroth 3842521344

BOSCH REXROTH Original product
Net price (excl. VAT)
€13.36
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842521344
Manufacturer no. 3842521344
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842521344
Country of originItaly
Customs tariff number39269097
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842521344

The QV 1 cross connector is a component of the section units in the longitudinal transport of the Bosch Rexroth TS 1 transfer system. It joins two parallel section units and sets their track spacing at a build width of 160 mm.

  • Defines the track spacing for a build width (BWT) of 160 mm
  • Polyamide PA 6 material for low weight and corrosion resistance
  • Matches the section assembly of the TS 1 transfer system

Technical data

TypeQV 1
Build width BWT160 mm
MaterialPA 6
Weight0.076 kg
More Information
ExecutionTEC
Manufacturer Nr.3842521344
ManufacturerBosch Rexroth
Country of ManufactureItaly
Weight76.000000
HS-Code39269097
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticityOriginal product
Condition of articleNew
