The HD 2 lift rotate unit raises workpiece pallets above the conveyor medium and turns them 180° on the Z axis. The ESD-capable version with 40 mm lift is suited to turning workpiece pallets directly above the conveyor section. For use in the TS 2 transfer system.
Lift Rotate Unit HD 2, ESD, 180° Turn, 40 mm Lift, 160 mm Track Width - Bosch Rexroth 3842525851
BOSCH REXROTH Original product
Net price (excl. VAT)
€4,907.61
Item BRR-3842525851
Manufacturer no. 3842525851
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842525851
Country of originGermany
Customs tariff number84313900
ConditionNew
Article
BRR-3842525851
Frequently Bought Together
- This Item: €4,907.61
- Strut Profile 30x30, Anodized Aluminum, Slot 8, Variable Length - Bosch Rexroth 3842990720-1000 €14.05
- Safety Cover 455 97,5 - Bosch Rexroth 3842545992 €222.55
Total price
The HD 2 lift rotate unit raises workpiece pallets out of the conveyor section and turns them on the Z axis. It is designed for use in the TS 2 transfer system and is intended for automated workpiece handling applications.
- 180° turning angle on the Z axis
- 40 mm lift for turning workpiece pallets directly above the conveyor section
- ESD-capable version for electrostatically protected work areas
- Supplied including fastening material
Technical data
| ESD | yes |
| Turning angle Z axis | 180° |
| Lift over conveyor medium [h0] | 40 mm |
| Track width in direction of transport [b] | 160 mm |
| Length in direction of transport [lT] | 240 mm |
| Dimension [c] | 42 mm |
| Dimension [d] | 42 mm |
| Workpiece pallet total weight [mG] | 16 kg |
| Max. permitted total mass moment of inertia | 0.65 kgm² |
| Scope of delivery | incl. fastening material |
| Required accessories | Stop gate VE 2/..., sensor M12x1, SN 4 mm |
| Weight | 22.2 kg |
| ESD version | TEC |
|---|---|
| Manufacturer Nr. | 3842525851 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.009900 |
| HS-Code | 84313900 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
