Strut Profile 15x180, 6x6070 mm, Anodized Aluminum, ESD - Bosch Rexroth 3842557242
Strut Profile 15x180, 6x6070 mm, Anodized Aluminum, ESD - Bosch Rexroth 3842557242 Dimensional drawing 3842557242

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Strut Profile 15x180, 6x6070 mm, Anodized Aluminum, ESD - Bosch Rexroth 3842557242

Bosch Rexroth ✓ Original product Brand new Made in Sweden

Anodized aluminum strut profile with a 15x180 mm cross-section and ESD certification for use in electrostatically protected assembly environments. Each packaging unit contains 6 profiles at 6070 mm length, with 9 open slots and a 45 mm modular dimension - fully compatible with the Bosch Rexroth profile system. Suited for load-bearing strut structures in production and laboratory settings.

Net
€1,707.82
excl. VAT
Item BRR-3842557242
Manufacturer no. 3842557242
Save Compare
Question about this item
Datasheet (PDF) 8 documents, all under Downloads
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Bosch Rexroth strut profile 15x180 is an anodized aluminum profile for demanding strut constructions in assembly, production, and ESD-sensitive environments. Its asymmetric 15x180 mm cross-section delivers high bending stiffness - area moment of inertia 321.7 cm⁴ in the x-direction - at a unit weight of just 3.1 kg. Each packaging unit contains 6 profiles in the standard length of 6070 mm.

  • ESD-rated (yes) - safe for use in electrostatically protected areas
  • 9 open slots, profile slot 10, 45 mm modular dimension - full compatibility with the Bosch Rexroth assembly system
  • High bending stiffness: lx = 321.7 cm⁴, Wx = 35.7 cm³
  • Anodized aluminum (color: natural) - corrosion-resistant and durable
  • Delivery unit: 6 pieces, profile type: standard

Technical data

PropertyValue
Cross-section15x180 mm
Length [L]6070 mm
Delivery unit6 pieces
Mass per piece [m]3.1 kg
Packaging unit weight134.4 kg
Profile slot10
Open slots9
Modular dimension45 mm
Profile typeStandard
Profile surface [A]11.6 cm²
Area moment of inertia X [lx]321.7 cm⁴
Moment of resistance X [Wx]35.7 cm³
Area moment of inertia Y [ly]3.2 cm⁴
Moment of resistance Y [Wy]4.2 cm³
MaterialAluminum, anodized
ColorNatural
ESDYes
Condition on deliveryPackaging unit in standard length
Recommended accessoriesCover cap 15x180, black ESD; Cover cap 15x180, signal gray
Weight134.4 kg
ManufacturerBosch Rexroth
Manufacturer Nr.3842557242
HS-Code76042100
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureSweden
Lenght6070 mm
