The HD 2 lift-rotate unit turns the workpiece pallet into the required orientation on TS 2plus transfer systems. On circulating systems without curves it keeps a constant pallet orientation. The 90 mm lift leaves room for side-mounted modules, and work operations on the unit are permitted.
Lift-rotate unit HD 2, b160 lT320, 180° rotation, ESD - Bosch Rexroth 3842525854
BOSCH REXROTH
Original product
Net price (excl. VAT)
€4,907.61
Item
BRR-3842525854
Manufacturer no.
3842525854
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.3842525854
Country of originGermany
Customs tariff number84313900
ConditionNew
Article
BRR-3842525854
Frequently Bought Together
-
This Item:
€4,907.61
-
Housing Element for HD 2/H Transfer System, 800 x 800 mm, 180° - Bosch Rexroth 3842552624
€819.40
-
PE 2 Positioning Unit, ESD, 160 mm Track Width for Workpiece Pallets - Bosch Rexroth 3842504706
€885.17
Total price
The HD 2 lift-rotate unit turns the workpiece pallet into the desired orientation and is designed for the Bosch Rexroth TS 2plus transfer systems. On circulating systems without curves it maintains a constant pallet orientation, so the front stays at the front.
- 180° rotation about the Z axis
- 90 mm lift above conveyor level, suitable when components are mounted at the side, such as identification and data storage modules
- Work operations on the unit are permitted without additional applied forces
- ESD version, delivered including fastening material
Technical data
| Article number | 3842525854 |
|---|---|
| ESD | yes |
| Track width in direction of transport (b) | 160 mm |
| Length in direction of transport (lT) | 320 mm |
| Rotation angle | 180° |
| Lift of WT above conveyor level (h) | 90 mm |
| Max. workpiece pallet total weight (mG) | 16 kg |
| Max. permitted total mass moment of inertia | 0.65 kgm² |
| Dimension c | 42 mm |
| Dimension d | 42 mm |
| Weight | 22.2 kg |
| Scope of delivery | Incl. fastening material |
| ESD version | TEC |
|---|---|
| Manufacturer Nr. | 3842525854 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.009900 |
| HS-Code | 84313900 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
