Conveyor section profile SP2/BH, anodized aluminum, slot 10, L 6070 mm - Bosch Rexroth 3842532696
Datasheet (PDF)
The product may differ from the illustration
Conveyor section profile SP2/BH for longitudinal transport in the Bosch Rexroth TS 2plus transfer system. Extruded aluminum profile, anodized, with profile slot 10, in 6070 mm standard length. It forms the load-bearing track of the belt and toothed-belt section units.

Conveyor section profile SP2/BH, anodized aluminum, slot 10, L 6070 mm - Bosch Rexroth 3842532696

BOSCH REXROTH Original product
Net price (excl. VAT)
€5,714.07
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842532696
Manufacturer no. 3842532696
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842532696
Country of originGermany
Customs tariff number76042100
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842532696
Frequently Bought Together
Total price

The SP2/BH section profile is the load-bearing extruded profile for longitudinal transport in the Bosch Rexroth TS 2plus transfer system. It forms the running track of belt and toothed-belt section units and is used in automation systems to convey workpiece pallets.

  • Extruded aluminum profile, anodized, in 6070 mm standard length
  • Profile slot 10 for connectors and accessories
  • High bending and torsional stiffness from the optimized cross-section

Technical data

Condition on deliveryPackaging unit in standard length
Profile slot10
ColorNatural
Delivery unit16
Length [L]6070 mm
Profile surface [A]12.4 cm²
Area moment of inertia in x-direction [Ix]53.7 cm⁴
Area moment of inertia in y-direction [Iy]28.6 cm⁴
Moment of resistance in x-direction [Wx]14 cm³
Moment of resistance in y-direction [Wy]13.8 cm³
Mass [m]3.3 kg/m
MaterialAluminum, anodized
Weight355 kg
Recommended accessoriesRoller elements, Cross Connector QV 2
More Information
ExecutionTEC
Manufacturer Nr.3842532696
ManufacturerBosch Rexroth
Country of ManufactureGermany
Weight0.100000
HS-Code76042100
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticityOriginal product
Condition of articleNew
