Leveling Foot Spindle M12, L145, ESD, Galvanized Steel - Bosch Rexroth 3842537224
Leveling Foot Spindle M12, L145, ESD, Galvanized Steel - Bosch Rexroth 3842537224 Dimensional drawing 3842537224

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Leveling Foot Spindle M12, L145, ESD, Galvanized Steel - Bosch Rexroth 3842537224

Bosch Rexroth ✓ Original product Brand new Made in Germany

Threaded M12 spindle for the modular leveling feet from Bosch Rexroth. It connects the foot to the profile and provides 80 mm of height adjustment. ESD-capable and made of galvanized steel, rated up to 20000 N.

Net
€5.79
excl. VAT
Item BRR-3842537224
Manufacturer no. 3842537224
Minimum order quantity: 20 pieces. This item is supplied in multiples of 20.
Save Compare
Question about this item
Datasheet (PDF) 8 documents, all under Downloads
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The M12 threaded spindle is a basic element of the modular leveling foot system from Bosch Rexroth. It links the leveling foot to the aluminum profile and is used to level and height-adjust frames, machine bases and workstations.

  • ESD-capable for applications with discharge requirements
  • 80 mm adjustment range for precise alignment
  • High load capacity up to 20000 N per foot
  • Galvanized steel for corrosion protection

The bearing ring is required as an accessory for assembly.

Technical data

Thread sizeM12
Length [L]145 mm
Adjustment range [V]80 mm
Force F20000 N
Profile slot8; 10
ESDyes
MaterialSteel, galvanized
Required accessoriesBearing ring
Packaging unit20 pcs
Weight0.122 kg
ManufacturerBosch Rexroth
Manufacturer Nr.3842537224
HS-Code73182900
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
Lenght145 mm
ESD versionESD (antistatic)
