Connects two slot-10 profiles with a positive-locking, conductive joint for ESD-compliant assembly structures. Made from galvanized steel with a PP centering pin; installation requires drilling jig 3842528574. Supplied in packs of 10 including 2 cover caps - ESD-rated cover cap 3842551055 available separately.
Bolt Connector Profile Slot 10, 45 mm, Galvanized, ESD-Conductive - Bosch Rexroth 3842555584
BOSCH REXROTH
Original product
Net price (excl. VAT)
€6.48
Item
BRR-3842555584
Manufacturer no.
3842555584
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.3842555584
Country of originGermany
Customs tariff number73269098
ConditionNew
Article
BRR-3842555584
Frequently Bought Together
-
This Item:
€6.48
-
Base Plate D44, Diecast Zinc Black, Slot 8 and 10 - Bosch Rexroth 3842538676
€8.33
-
Leveling Foot Spindle M12, L145, ESD, Galvanized Steel - Bosch Rexroth 3842537224
€5.79
Total price
The Bolt Connector 10 D17x45 joins two aluminum profiles with slot 10 in a precisely centered, conductive connection - making it suitable for ESD-protection concepts in manual assembly lines. Installation requires drilling jig 3842528574. Two PP cover caps are included; for fully ESD-compliant covering, order ESD cover cap 3842551055 separately.
- Conductive profile-to-profile connection for slot 10 - supports ESD earthing continuity in assembly structures
- Galvanized steel construction - durable and corrosion-resistant for continuous production use
- Integrated PP centering pin ensures accurate, repeatable positioning
- Pack of 10 with 2 cover caps included - cost-effective for series installation
- Note: included cover caps are not ESD-compatible; use article 3842551055 for ESD-rated covering
Technical data
| Attribute | Value |
|---|---|
| Profile slot | 10 |
| Profile slot P1/P2 | 10 / 10 |
| Length L | 45 mm |
| Length l2 | 28 mm |
| Material | Steel, galvanized |
| Material information | Bolt connector: steel, galvanized; centering pin and cover caps: PP |
| Color | Signal gray |
| ESD | Yes (conductive connection; included cover caps are not ESD-compatible) |
| Packaging unit | 10 pieces |
| Scope of delivery | Incl. 2 cover caps |
| Required accessories | Drilling jig 3842528574 |
| Recommended accessories | Cover cap ESD 3842551055 |
| Weight | 0.076 kg |
| Weight | 0.076000 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Manufacturer Nr. | 3842555584 |
| HS-Code | 73269098 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Lenght | 45 mm |
| ESD version | ESD (antistatic) |
