Strut Profile 45x90x90L, Slot 10, ESD, Anodized Aluminum - Bosch Rexroth 3842537823
Datasheet (PDF)
The product may differ from the illustration
Angled strut profile 45x90x90L in anodized aluminum with profile slot 10 and 8 open slots. ESD-capable for building dissipative frames, racks and fixtures. Supplied as a packaging unit of 8 profiles in the 6070 mm standard length.

Strut Profile 45x90x90L, Slot 10, ESD, Anodized Aluminum - Bosch Rexroth 3842537823

BOSCH REXROTH Original product
Net price (excl. VAT)
€4,040.90
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842537823
Manufacturer no. 3842537823
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842537823
Country of originGermany
Customs tariff number76042100
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842537823

The Bosch Rexroth strut profile 45x90x90L is an angled aluminum profile from the modular assembly technology system. It serves as a load-bearing base element for frames, racks and fixtures, and its ESD property makes it suitable for electrostatically dissipative applications.

  • Angled cross-section 45x90x90L with profile slot 10 and 8 open slots
  • Anodized aluminum in natural color
  • ESD-capable for dissipative work areas
  • 45 mm modular dimension for flexible construction

Technical data

AttributeValue
Cross-section45x90x90L
Dimensions45x90x90
Modular dimension45 mm
Profile slot10
Open slots8
Profile typeangled
ESDyes
ColorNatural
MaterialAluminum, anodized
Length (L)6070 mm
Profile surface (A)21.2 cm²
Area moment of inertia in x-direction (Ix)152.1 cm⁴
Area moment of inertia in y-direction (Iy)152.1 cm⁴
Moment of resistance in x-direction (Wx)19.1 cm³
Moment of resistance in y-direction (Wy)32.6 cm³
Torsional moment of inertia (It)34.9 cm⁴
Moment of torsion resistance (Wt)11.6 cm³
Mass (m)5.7 kg/m
Profile machiningM12: in the core bore at the intersection of slots A and H
Condition on deliveryPackaging unit in standard length
Delivery unit8
Weight per packaging unit292 kg
Recommended accessoriesCover cap 45x90x90 (black or signal gray, also with hole)
More Information
Manufacturer Nr.3842537823
ManufacturerBosch Rexroth
Country of ManufactureGermany
Weight292.000000
Lenght6070 mm
NoteGemäß der aktuellen Preisstruktur werden für Bestellungen von Profilen mit einer Länge von 1500 mm zusätzliche Kosten in Höhe von 80,00 Euro berechnet.
HS-Code76042100
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticityOriginal product
Condition of articleNew
