Load-bearing strut profile 80x80L in the 4NVS configuration, made of anodized aluminum, ESD-capable and natural in color. Four open slots (slot 10) and a 40 mm grid support the construction of stable frames and machine racks. Supplied in 6070 mm standard length, packaging unit of 6.
Strut Profile 80x80L 4NVS, ESD, Slot 10, Anodized Aluminum - Bosch Rexroth 3842538334
BOSCH REXROTH
Original product
Net price (excl. VAT)
€2,804.30
Item
BRR-3842538334
Manufacturer no.
3842538334
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.3842538334
Country of originGermany
Customs tariff number76042100
ConditionNew
Article
BRR-3842538334
Frequently Bought Together
-
This Item:
€2,804.30
-
Strut Profile 40x80L D17V/D17V, Anodized Aluminum, 1000 mm - Bosch Rexroth 3842993138-1000
€37.92
-
Strut Profile 40x40L, 4 Slots, ESD-Suitable, Anodized Aluminum - Bosch Rexroth 3842993125
€29.69Show details
Total price
The strut profile 80x80L in the 4NVS configuration is a load-bearing base element made of anodized aluminum for machine, fixture and equipment construction. It is suited to building stable frames, racks and protective enclosures and is ESD-capable.
- four open slots (slot 10) for flexible connections and add-on parts
- 40 mm modular grid for systematic module and hole-pattern planning
- ESD-capable for applications with electrostatic requirements
- symmetrical cross-section with identical strength values in the x and y directions
Technical data
| Cross-section | 80x80L 4NVS |
| Dimensions | 80x80 |
| Profile type | 4NVS |
| Profile slot | 10 |
| Open slots | 4 |
| Modular dimension | 40 mm |
| Length [L] | 6070 mm |
| ESD | yes |
| Color | Natural |
| Material | Aluminum, anodized |
| Profile surface [A] | 19.3 cm² |
| Area moment of inertia x [Ix] | 142.5 cm⁴ |
| Area moment of inertia y [Iy] | 142.5 cm⁴ |
| Moment of resistance x [Wx] | 35.6 cm³ |
| Moment of resistance y [Wy] | 35.6 cm³ |
| Torsional moment of inertia [It] | 92 cm⁴ |
| Moment of torsion resistance [Wt] | 16.8 cm³ |
| Mass [m] | 5.2 kg/m |
| Condition on delivery | Packaging unit in standard length |
| Delivery unit | 6 |
| Weight (packaging unit) | 235 kg |
| Recommended accessories | Cover cap 80x80, signal gray; Mounting hole plug 80x80, black |
| Weight | 235.000000 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Manufacturer Nr. | 3842538334 |
| HS-Code | 76042100 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Lenght | 6070 mm |
