Bearing Pedestal designLINE, Painted Diecast Zinc, Slot 10 - Bosch Rexroth 3842547869
Datasheet (PDF)
The product may differ from the illustration
Swiveling bearing pedestal of the designLINE series for mounting heavy constructions in aluminum profile systems. The painted diecast zinc version with special white aluminum paint (RAL 9006) provides a high-quality appearance. For profiles with slot 10, bending moment up to 400 Nm.

Bearing Pedestal designLINE, Painted Diecast Zinc, Slot 10 - Bosch Rexroth 3842547869

BOSCH REXROTH Original product
Net price (excl. VAT)
€59.94
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842547869
Manufacturer no. 3842547869
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842547869
Country of originGermany
Customs tariff number83024900
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842547869
Frequently Bought Together
Total price

The designLINE bearing pedestal serves as a swiveling bearing element for heavy constructions in aluminum profile system construction. The designLINE version with special white aluminum paint (RAL 9006) is designed for a high-quality appearance and is intended for design engineers and equipment builders.

  • Swiveling support of heavy constructions
  • Bending moment up to 400 Nm
  • High-quality appearance through special white aluminum paint RAL 9006
  • For profiles with slot 10

Technical data

MaterialDiecast zinc, painted
ColorWhite aluminum (RAL 9006)
Profile slot10
Bending moment400 Nm
Fastening material2x cylinder head screw ISO4762-M8x16, 2x T-nut slot 10 M8
Material informationBearing pedestal: diecast zinc, painted; fastening material: steel, galvanized; clamping lever handle: diecast zinc, black plastic coated; cover cap: PP, signal gray
Scope of deliveryIncl. fastening material (FS), 2 x cover cap, 2 x bolt, clamping lever and standard parts for clamping the bearing pedestal
Packaging unit1
Weight0.938 kg
More Information
Manufacturer Nr.3842547869
ManufacturerBosch Rexroth
Country of ManufactureGermany
Weight0.938000
HS-Code83024900
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticityOriginal product
Condition of articleNew
