Carrying Plate Aluminum 19.05 mm, 1200 x 1200 mm, for WT 2/H Workpiece Pallet - Bosch Rexroth 3842548419
Datasheet (PDF)
The product may differ from the illustration
Universal aluminum carrying plate for self-assembly of WT 2/H workpiece pallets. Supplied completely drilled and ready for assembly, designed for high loads and large workpiece pallets. Plate thickness 19.05 mm, size 1200 x 1200 mm.

Carrying Plate Aluminum 19.05 mm, 1200 x 1200 mm, for WT 2/H Workpiece Pallet - Bosch Rexroth 3842548419

BOSCH REXROTH Original product
Net price (excl. VAT)
€2,463.62
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842548419
Manufacturer no. 3842548419
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842548419
Country of originGermany
Customs tariff number84799070
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842548419
Frequently Bought Together
Total price

The WT 2/H aluminum carrying plate is used to self-assemble workpiece pallets in the Bosch Rexroth transfer system. It suits users who configure workpiece pallets for product support or for specific customer requirements, combining frame modules, carrying plates, locating bushes and the required fixing elements.

  • Completely drilled and ready for assembly
  • Universal aluminum carrying plate for high loads and large workpiece pallets
  • Can be combined with the WT 2/H workpiece pallet kit
  • Available in two plate thicknesses (12.70 mm and 19.05 mm); this version 19.05 mm

Technical data

FeatureValue
MaterialAluminum
Plate thickness (dPL)19.05 mm
Workpiece pallet width (bWT)1200 mm
Workpiece pallet length (lWT)1200 mm
Dimension c995 mm
Dimension d995 mm
Flatness1.2 mm
Workpiece pallet total weight (mG)240 kg
Weight73.54 kg
More Information
ExecutionTEC
Manufacturer Nr.3842548419
ManufacturerBosch Rexroth
Country of ManufactureGermany
Weight0.009900
HS-Code84799070
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticityOriginal product
Condition of articleNew
